It’s been an exciting couple of years at GB Controls as we continue to see year-on-year growth across heat pump control panels and refrigeration panels. From enhanced monitoring capabilities to improved cost efficiency, our innovative control solutions meet business demands and reduce their carbon footprint.
As we head through the 2nd quarter of the 25/26 financial year, it’s a great time to review our top performing products from the previous 18 months and review their benefits. And with continued investment into product development, we are proud to announce innovative new products to the market in 2025, with new enhanced capabilities to meet increasing business demands and eco-friendly requirements.
Introducing Our New Products
GB Controls Temperature Monitoring Panels
The GB Controls Temperature Monitoring Panels provide reliable solutions for tracking and safeguarding temperature and humidity conditions across critical environments. Available in LAN and 4G models, these temperature monitoring panels deliver real-time monitoring, relay-driven alarms for local sounders or beacons, and email alerts when conditions move outside defined limits. They feature robust IP55-rated enclosures, mains power with backup options, and simple setup methods designed to suit different operational needs.
- Continuous monitoring of temperature and humidity conditions.
- Configurable alarms with relay outputs for beacon/sounder activation.
- Email alerts supported across both product ranges.
- LAN models: browser setup, mobile app access, up to 2 sensors.
- 4G models: SMS/email alerts, remote setup via SMS/API, up to 4 sensors.
Connectivity and alerting capabilities
The LAN models support up to two sensors, with setup via a web browser and a mobile app for remote access. The 4G models support up to four sensors, with flexible setup via USB, SMS, or HTTP API, and offer alerts via both email and SMS to multiple recipients.
- LAN models: Best for environments with stable Ethernet access, simple browser setup, and mobile app monitoring.
- 4G models: Best for remote or flexible deployments, supporting more sensors, multi-recipient alerts, and setup via SMS/API.
8 Channel Temperature Data Logger
The GB Controls 8 Channel Temperature Data Logger provides a powerful and flexible solution for monitoring and recording temperature across multiple points. With support for up to eight probes, it enables comprehensive tracking of coldroom conditions and generates detailed real-time trend graphs through its built-in web server. Logged data can be downloaded in .CSV format for further analysis or transferred directly via USB for convenience.
The unit allows users to configure probe names, alarm thresholds, and delays through the web interface, while advanced settings such as IP configuration and logging intervals can be managed via the integrated HMI. Designed with an IP65-rated enclosure, mains power, and volt-free alarm outputs for integration with BMS systems, it offers both robust operation and seamless data accessibility.
- Monitors up to 8 probes for multi-point temperature tracking.
- Web-based interface with real-time graphing and .CSV data export.
- Built-in HMI for advanced setup, SD card management, and USB transfer.
- Adjustable alarms and delays with volt-free outputs for local/BMS integration.
- IP65-rated enclosure with mains power for reliable operation.
Personnel Safety Alarm
The GB Controls Personnel Safety Alarm (PSA) is a high-integrity, fail‑safe system designed to raise an immediate alert if someone is trapped in a walk‑in coldroom or freezer. Supplied as a kit (PSA unit, illuminated coldroom pushbutton with stainless‑steel guard, and external beacon/sounder), it provides a robust, self‑checking safety layer built for harsh environments.
Dual‑channel processing continuously supervises the system and exposes faults via monitored alarm and fault relays. An integrated 95 dB beacon/sounder, 10‑hour battery backup for mains failures, connections for up to 2 coldroom buttons, IP65 housing, and status/alarm LEDs round out a dependable, compliance‑ready package (see BS EN 378‑1:2016 Annex D).
- Fail‑safe, dual‑watchdog design with monitored alarm and fault relays.
- Integrated 95 dB beacon/sounder plus external beacon/sounder with connection monitoring.
- Up to 2 coldroom pushbuttons with supervised wiring (≤30 m).
- 10‑hour battery backup to remain operational during mains failures.
- IP65 enclosure; 85–264 Vac supply; status/alarm LEDs
- Available as kit GBC2000‑PSK
Coldroom Door Open Alarm
The GB Controls Door Open Alarm alerts staff when a coldroom door is left open, helping cut unnecessary energy use in line with Cold Chain Federation benchmarking and reducing risks from temperature rise during prolonged openings.
It offers two configurable time ranges (0–30 or 0–10 minutes), two independent door inputs, and compatibility with NO/NC switches and PNP inductive proximity switches. Door/alarm LEDs provide clear status, while a relay output can drive external systems. An IP65 enclosure, 85–264 Vac supply, low power consumption, and an optional yellow or blue illuminated sounder complete a simple, reliable install.
- Timed alert windows: 0–30 or 0–10 minutes.
- Two independent door switch inputs (NO/NC & PNP proximity supported).
- Relay output on door‑open or alarm with door/alarm LED indication.
- Adjustable alarm intensity with coloured illuminated sounder.
- IP65 enclosure, 85–264 Vac, low power consumption for efficient operation.
GB Controls Existing Range of Standard Control Panels
Our Standard Control Panels provide a flexible, reliable, and cost‑effective solution for a wide range of refrigeration and evaporator applications. Designed and manufactured in the UK with over 40 years’ experience and ISO 9001 accreditation, these pre‑configured control systems offer high quality, rapid delivery, and consistent performance across industry sectors such as retail, catering, healthcare and cold‑storage.
Standard Features (applicable across all panel types)
- Digitally controlled operation via Eliwell EWNext controller
- Robust IP‑rated enclosures (polymer or mild‑steel depending on model)
- Integrated safety and load protection (MCBs, isolators, over‑current)
- NTC temperature probes included as standard
- Visual indication via illuminated switches or controller display
- Provision for door‑interlocks, defrost heaters, fan and drain heater control
- Compatible with modern, low‑GWP refrigerants and HACCP compliance logging (via optional module)
Universal Control Panel Range
GB Controls’ Universal Control Panel Range offers an economical and compact solution for basic refrigeration control. Housed in a top‑entry, IP55 technopolymer enclosure, these panels deploy the EWNext digital controller to manage evaporator fans, defrost heaters, lighting and door switches. The simple, modular design ensures rapid installation and reliability in smaller cold‑room or multi‑evaporator setups.
Despite its compact footprint, the Universal Range delivers high utility, including: door interlocked isolator, illuminated switches, and MCB protection for essential loads. It’s ideal for back‑of‑store installations where space is at a premium but operational safety and efficiency remain critical.
More Details About Universal Control Panels
Condensing Unit Starter Panel Range
The Condensing Unit Starter Panel Range brings premium‑grade starter control for condensing units. Built within mild steel enclosures, these panels offer enhanced durability and mounting space for heavier MCBs, contactors and monitoring devices. Fully configurable, they are designed to support large‑scale refrigeration installations and demanding environmental conditions.
These panels facilitate smooth start‑up sequences, protective interlocks so that operators benefit from precise compressor control and energy‑efficient operation – making them suitable for retail, food distribution, and multi‑compressor refrigeration environments.
More Details About Condensing Unit Starter Panels
Digital Evaporator Control Panel Range
The Digital Evaporator Control Panel Range is a high‑specification option for evaporator control applications. Housed in robust steel cabinets, these panels feature advanced EWNext controllers.
Engineered for precise defrost cycles and multi‑fan sequencing, these panels help maintain consistent cold‑room temperatures, reduce energy consumption, and improve system longevity. With added diagnostic capabilities and enhanced load protection, they are designed to meet demanding industrial refrigeration needs in commercial kitchens, cold stores and supermarkets.
More Details About Digital Evaporator Control Panels
Digital Coldroom Control Panel Range
With the Digital Coldroom Control Panel Range, GB Controls deliver comprehensive coldroom management in a refined package. These units integrate full controller functionality, multi‑zone sensors, defrost & lighting control, and door interlock systems within a high‑spec mild steel enclosure.
Designed for environments where temperature stability, HACCP compliance and operational traceability are essential, these panels offer all the features of a starter panel and evaporator panel combined. They are ideal for facilities like hospitals, pharmaceuticals, and food storage centres where regulation and consistency are paramount.
More Details About Digital Coldroom Control Panels
Digital Auto Change‑Over Panel Range
The Digital Auto Change‑Over Panel Range automates seamless switching between two independent refrigeration systems on an alternate duty cycle. Change-over is achieved automatically by either a pre-set time, condensing unit fault (if connected), temperature alarm or manually by the door mounted selector switch.
Built to high standards in steel cabinets, these panels support full coldroom control or evaporator-only installations, controlling cooling according to temperature and load balancing logic.
By automatically alternating between systems, these panels not only optimise system efficiency and service intervals but also reduce wear on equipment and offer redundancy. They are especially beneficial in mission‑critical applications where downtime is unacceptable.
